LP1lightplane

Description

Capacitive X/Y/Z Controller with CV Record / Looping

LP1lightplane is an expanded, tri-dimensional LS1 lightstrip. The same functions are exposed on either axis plus pressure (z) for three times the fun!

The LP1lightplane is a capacitive surface that generates three-­dimensional CVs plus a GATE signal along with finger movements, and “pressure” of your finger on its surface.

It can also record those movements and loop them.

• MODE button switches between LIVE, HOLD and REC modes
• While LOOP mode is active, MODE button will HOLD or (as well as Gate In) reactivate it.
• Select between recording pressure along with axis, or recording just X and Y axis for longer.
• Gate Out or Gate In jack (depending on jumper setting on the back; Gate In mode allows for loop synchronization
• CVZ – Pressure CV output
• CVY – Vertical axis CV output
• CVX – Horizontal axis CV output
• Three independent jumpers on the back side to select CV range between 5V and 10V
• Orientation jumper allows turning it 180 degrees (jacks up or down)

Specs:

• width: 16hp
• depth: 18mm
• power: 210 mA +12V, 8 mA -12V, 0 mA 5V

LP1lightplane_Manual_Sep2013
